Features:

• Constant voltage or current
• Dual backlit LCD displays for voltage and current
• Short circuit protection
• Current limiting
• High load/line regulation
• Low noise/ripple
• Banana plug output terminals

Specifications:

• Display: Dual LCD
• Display Accuracy (V, A): ±(1.5%rdg); ±(2%rdg)
• Voltage Output, DC: 18.0 Volts
• Current Output, DC: 0 – 3.00 Amps
• Ripple and Noise: <0.5mV/<3mA
• Line Regulation: <0.01% 3mV/<0.2% 3mA
• Load Regulation: <0.01% 2mV/<0.2% 3mA
• Power: 115V/230V; 50/60Hz
• Warranty: 1 year
• Dimensions (WxHxD): 9.4 x 4.25 x 6" (240 x 108 x 154mm)

The 382202 is a DC power supply which provides an adjustable 0 to 30 Volts and 0 to 1 Amp output. Features dual backlit LCD display for current and voltage, short circuit and overload protection. Operates from 120VAC ±10%/60Hz power source. Banana plug outputs. Complete with power cord.
