Product Details
＋
ISPRO C 80/275 (1 1), Class II / Type 2 / C, Modular Surge Protection Device (SPD) 2 Pole 40kA, 275VAC, DIN Rail Mount. For Sub Distribution Boards
Specifications
| Iskra Doo part number | ISPRO C 80/275 (1 1) |
| Nominal Voltage | 275VAC |
| No of Poles Included | 2 (via 2 modules) |
| Category IEC / EN / VDE | Class II / Type 2 / C |
| Location of use | Sub Distribution Boards |
| Additional Remote Contacts | NO |
| Protection modes | L/N-PE |
| Protective element | MOV GDT |
| Surge discharge rating | Imax up to 40 kA |
| Internal protection and safety | Thermal disconnector in each MOV |
| Standards | IEC/EN 61643-11 |
