| Product Attribute | Attribute Value |
|---|---|
| Alternate Mfr Part Number | PLC-RSP- 24DC/21-21 |
| Approvals | GL, UL Recognized, cULus Listed |
| Contact Form | DPDT |
| Current Rating | 6 A |
| For Use With | Phoenix Contact PLC series |
| Function | PLC |
| Mounting Type | DIN Rail |
| Relay Type | Electromechanical Relay |
| Series | |
| Special Features | LED Indicator ; PLC Terminal Block |
| Termination | Spring Cage |
| UPC Code | 4046356050913 |
| Voltage Rating | 250 VAC, 250 VDC |
| Voltage, Control | 24 VDC |
Overview
Phoenix Contact PLC-INTERFACE Series | Switch Modules - Narrow and Powerful Compact Relay System:
The PLC-INTERFACE relay system is the high-performance interface between the controller and system peripherals. PLC-INTERFACE provides you with a comprehensive range of highly compact, plug-in relays and solid-state relays. This includes extensive accessories and system cabling.
The PLC-INTERFACE Relay System acts as the high performance interface between the controller and system I/O devices. The new electromechanical relay with manual actuation is particularly suited for maintenance and commissioning as it can be operated manually. The PLC-INTERFACE relay system acts as the highperformance interface between the controller and system I/O devices. New variants allow you to isolate and switch signals safely in the potentially explosive areas of Zone 2. The PLC-INTERFACE relay system from Phoenix Contact acts as the high-performance interface between the controller and system I/O devices.
PLC-INTERFACE with Switch Features:
Series Features:
