Product Description
-
An isolator is a device or component used to separate or isolate electrical circuits, systems, or components to ensure safety, protect equipment, and control the flow of electricity
-
Isolators are crucial in various applications, including electrical engineering, telecommunications, and industrial processes
Product Specification
|
Brand |
Schneider |
|
Product Code |
A9S2P125 |
|
Range of product |
ISW 40...125 |
|
Range |
Acti 9 |
|
Product or component type |
Isolator |
|
Device application |
Isolation |
|
Complementary |
|
|
[Ie] rated operational current |
125 A 240 V AC |
|
[Ui] rated insulation voltage |
6 kV |
|
[Uimp] rated impulse withstand voltage |
500 V |
|
Poles description |
2P |
|
Rated breaking capacity |
2.5 kA |
|
Short-circuit withstand |
20 A |
|
[Us] rated supply voltage |
48 V DC 1P 100 V DC 2P |
|
Utilisation category |
AC-22 |
|
Total number of 18 mm modules |
2 |
|
Product destination |
Distribution board |
|
Environment |
|
|
Ambient air temperature for operation |
-20...50 °C |
|
Pollution degree |
3 |
|
Standards |
IEC 60669-1 |
|
IEC 60947-3 |
|
